3.5 CORE COPPER XLPE UNARMOURED POWER CABLES

An Unarmoured Cables have the characteristics of internal electricity and external insulation. It is easy to install and use. These cables work in both dry and moist conditions. They are highly flexible for application in different electrical environment. These control cables are used in tool machines, steel production units & electrical substations.

Technical Data

Operating Temp : -20°C to max.+90°C Nominal Voltage : 1100 V Test Voltage : 3000 V Insulation Resistance : Min. 10 MΩ x km Min. Bending Radius : Single Core : 15 x Overall Diameter : Multi Core : 12 x Overall Diameter

Key Feature

High Mechanical Strength & Better Electrical Properties.
Excellent Conductor of Heat and Electricity.
High Magnetic Conductivity and Resist External Forces.

Conductor

Copper Stranded Wires Class 2

Insulation

XLPE-Cross Linked Polyethylene Compound

Armouring

Single layer of GS Flat Strips

Outer Sheath

PVC TYPE ST-2 (Option : FR Type / FRLS Type)

Application

It is most suitable for underground cabling such as in sewers or underground transport networks or outdoor walls via cable cleats. It is used in industrial applications like in cable trays and raceways. Many cities and municipalities allow the use of these cables in residential and commercial applications.

Sr. No.

No. of cores & cross-sectional Area/Neutral Core (Sq. mm.)

Thickness of XLPE Insulation mm

Inner Sheath PVC Thickness mm

Outer Sheath PVC Thickness mm

Approx Outer Sheath O/D mm

Max. DC Conductor Resistance At 20°C (Ohm/Km)

Approx Weight KG/km

Current Ratings (Amp.)

Power Core mm

Neutral Core mm

Direct in Ground

In Air

3.5 X 25/16

0.9

0.7

0.30

2.0

22.0

0.727

1125

120

125

3.5 X 35/16

0.9

0.7

0.30

2.0

24.0

0.524

1425

145

155

3.5 X 50/25

1.0

0.9

0.30

2.0

27.0

0.387

1980

170

190

3.5 X 70/35

1.1

0.9

0.40

2.2

31.0

0.268

2680

210

235

3.5 X 95/50

1.1

1.0

0.40

2.2

34.0

0.193

3580

250

290

3.5 X 120/70

1.2

1.1

0.40

2.2

38.0

0.153

4480

285

330

3.5 X 150/70

1.4

1.1

0.40

2.4

43.0

0.124

5485

315

375

3.5 X 185/95

1.6

1.1

0.50

2.6

46.0

0.0991

6785

355

435

3.5 X 240/120

1.7

1.2

0.60

2.8

52.0

0.0754

8675

410

510

3.5 X 300/150

1.8

1.4

0.60

3.0

57.0

0.0601

10780

460

590
